EI3011-EI5423 Series Small reactor
Product Parameter
| Place of Origin | Dezhou,China |
| Usage | Electronic, electric |
| Phase | Single Phase |
| Voltage | 230V AC |
| Frequency | 50 to 60Hz |
| Available in various voltages | |
| Coil Structure | TOROIDAL |
| Coil Number | as requested |
| Product name | PCB Mount Encapsulated Transformer |
| Material | core, wire, bobbin |
| Coil Structure | TOROIDAL |
| Certification | ISO90012008 |
| Package | Carton |
| Shipping Term | Sample Express,Batch orders according to customer requirements |
| FOB Port | Qingdao, Xingang |
| MOQ | 3000 Unit |
| Encapsulated mini power Transformer supplier | |
| Sample Cost | Free samples available |
| Usage | Electronic |
| Features | Potted under vacuum |
SCHEMATIC DIAGRAM
Electronic Specifications
|
Structure |
Outline dimension drawing |
| EI3011Series |  |
| EI3013Series |  |
| EI3016Series |  |
| EI3018Series |  |
| EI3023Series |  |
| EI3814Series |  |
| EI3816Series |  |
| EI4215Series |  |
| EI4221Series |  |
| EI4817Series |  |
| EI4821Series |  |
| EI5423Series |  |
Key Specification
|
Model |
Inductance(mH) |
Overall dimensions A*B*C(mm) |
Pin Distance(mm) |
Array Distance(mm) |
Bobbin(mm) |
|
EI3011 |
/ |
32.8*27.8*21.8 |
5 |
20 |
EI30*10.5 |
|
EI3013 |
/ |
32.8*27.8*24 |
5 |
20 |
EI30*12.5 |
|
EI3016 |
/ |
32.8*27.8*26.9 |
5 |
20 |
EI30*15.5 |
|
EI3018 |
/ |
32.8*27.8*29.5 |
5 |
20 |
EI30*18 |
|
EI3023 |
/ |
32.8*27.8*34.8 |
5 |
20 |
EI30*23 |
|
EI3814 |
/ |
41*35.0*27.8 |
5 |
25 |
EI38*13.5 |
|
EI3816 |
/ |
41*35.0*29.5 |
5 |
25 |
EI38*15.5 |
|
EI4215 |
/ |
45*38.1*32.5 |
5 |
25 |
EI42*14.5 |
|
EI4221 |
/ |
45.3*38.4*37.8 |
5 |
25 |
EI42*20.5 |
|
EI4817 |
/ |
51.3*43.3*35.3 |
5 |
27.5 |
EI48*16.8 |
|
EI4821 |
/ |
51.3*43.3*39 |
5 |
27.5 |
EI48*20.5 |
|
EI5423 |
/ |
57.1*48*44.5 |
5 |
30.5 |
